AEM Water Temp Sensor Kit 3/8″ NPT

Description

AEM Water Temp Sensor Kit. 3/8″NPT. Includes: Water Temp Sensor, 3/8″NPT Aluminum Bung, Connector & Pins

• Accuracy: < 2 °C / 3.6 °F
• Operating Temp: -40C to 135C / -40F to 275F
• Resistive Range (Ω): See Table
• Dissipation Constant: 24 mW/ °C. The ratio, at a specified ambient temperature, of the change in the power dissipation of the sensor to the resultant temperature change of the thermistor. Test medium: silicone oil.
• Thermal Time Constant: 20-30 sec. The time required for the sensor to achieve 63.2% of its steady state value when subjected to a step change in ambient temperature [Tc=(Tf-Ti)*63.2%+Ti]. Test medium: silicone oil.
• Sensor Body Material: Brass
• Thread: 3/8″-18 NPT
• Hex Size: 3/4″
• Installation Torque: 20Nm / 15 ft-lbs
• Weight: 39.5g
• Elec. Termination: Weatherproof connector. Includes mating connector, pins & wire seals
• Includes: Water Temp Sensor, 3/8″-18 NPT Aluminum Bung, Connector, Pins & Wire Seals
